Description

A glowing selection outline as a post-process — no per-object material changes. Flip Render CustomDepth on an actor and it lights up.

It reads the Custom Depth buffer, samples four diagonal neighbours per pixel and differences them into the object's silhouette, then glows that edge in your highlight colour with a soft pulse. Turn anything up: thickness, glow, pulse speed. Want the whole object tinted, not just the rim — push Fill Opacity. It's all nodes, so you can crack it open and see exactly how the edge falls out of the depth difference.

Settings you have to set

This is a Post Process material — none of these come across in the paste, so set them or it won't show:

  • Material Domain → Post Process (collapses the graph to Emissive Color)
  • Blendable Location → Before Translucency (stops the outline shimmering under TAA/TSR)
  • Project Settings → Rendering → Custom Depth-Stencil Pass → Enabled with Stencil
  • On each actor you want highlighted: Render CustomDepth Pass → on
  • Add the material to a Post Process Volume (Post Process Materials array), or AddOrUpdateBlendable it from Blueprint on hover/select. Use a global volume with Infinite Extent (Unbound) if it should apply everywhere.

Optional textures (bring your own)

Procedural by default — works with nothing plugged in.

  • Pattern Mask — flip on Use Pattern Mask and drop in a grayscale map (dashes, scanlines, hazard stripes) to break up the glow.
material graph

Preview only · open in editor for full material editing

Want this graph on your blog or forum?

0 comments

Sign in to join the discussion.

No comments yet. Be the first.

source
View T3D source (174 KB)expand
Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_0"
   Begin Object Class=/Script/Engine.MaterialExpressionComment Name="MaterialExpressionComment_C0"
   End Object
   Begin Object Name="MaterialExpressionComment_C0"
      SizeX=470
      SizeY=640
      Text="01 Highlight"
      CommentColor=(R=0.665387,G=0.258183,B=0.023153,A=1.000000)
      MaterialExpressionEditorX=-2080
      MaterialExpressionEditorY=-560
      MaterialExpressionGuid=165BFE728339E55DA14B9E8AB1D565CB
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpressionComment="/Script/Engine.MaterialExpressionComment'MaterialExpressionComment_C0'"
   CommentColor=(R=0.665387,G=0.258183,B=0.023153,A=1.000000)
   NodePosX=-2080
   NodePosY=-560
   NodeWidth=470
   NodeHeight=640
   NodeComment="01 Highlight"
   NodeGuid=467CA285E2B3E10B3DCA6C88CFC4FFD2
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_1"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_1"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_1"
      ParameterName="Highlight Color"
      DefaultValue=(R=1,G=0.55,B=0.1,A=1)
      Group="01 Highlight"
      Desc="Outline / glow colour. Push values above 1 for a bloomed look."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=-480
      MaterialExpressionGuid=DA0A0BBF2627F811C8BA3413EDCCA964
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_1'"
   NodePosX=-2000
   NodePosY=-480
   NodeGuid=2CAE2FDBB4E30EEFAC7A57BF73AF6330
   CustomProperties Pin (PinId=D2D17418E48FF288DB5ED3BFA62FED99,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_66 55DE238852BCB9C775D5E4087D32DBD9,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=CC90A0FED59E25CD3045432A8C5D77FF,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=D28AFD5730BBC97E3ED42633A9D8B79B,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=9B90A53F0CD0AFA79D847008006CE5E4,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=F75029F7117BA4915755E038CF0A8D64,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_2"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_2"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_2"
      ParameterName="Glow Intensity"
      DefaultValue=3
      SliderMin=0
      SliderMax=10
      Group="01 Highlight"
      Desc="Brightness multiplier on the highlight colour."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=-280
      MaterialExpressionGuid=25287302BCC5AD3F8D12648C315FB5DC
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_2'"
   NodePosX=-2000
   NodePosY=-280
   NodeGuid=111395A2AE524FD6EAEBA5976CC1A7A4
   CustomProperties Pin (PinId=309C795CE51109EF2D22B09F599ACD67,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_65 68F3E03573F42A2BF27CD99FC9A8ADD8,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_3"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_3"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_3"
      ParameterName="Outline Thickness"
      DefaultValue=2
      SliderMin=0.5
      SliderMax=6
      Group="01 Highlight"
      Desc="Edge sample spread in pixels — how thick the outline reads."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=-80
      MaterialExpressionGuid=FBD04D8ED3FC87CA7F26EFBBACF4EB60
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_3'"
   NodePosX=-2000
   NodePosY=-80
   NodeGuid=E143CDAEE7E91AD0E82E6E385444316C
   CustomProperties Pin (PinId=BFAFAD8E505702A7DF1BD3DF9C43F7AB,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_19 09A2BC3ED007F81444D39A14F73FDD69,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_4"
   Begin Object Class=/Script/Engine.MaterialExpressionComment Name="MaterialExpressionComment_C4"
   End Object
   Begin Object Name="MaterialExpressionComment_C4"
      SizeX=470
      SizeY=440
      Text="02 Pulse"
      CommentColor=(R=0.462077,G=0.162029,B=0.023153,A=1.000000)
      MaterialExpressionEditorX=-2080
      MaterialExpressionEditorY=140
      MaterialExpressionGuid=596A6CE890E0EDAF0B9C8D3A7D45E663
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpressionComment="/Script/Engine.MaterialExpressionComment'MaterialExpressionComment_C4'"
   CommentColor=(R=0.462077,G=0.162029,B=0.023153,A=1.000000)
   NodePosX=-2080
   NodePosY=140
   NodeWidth=470
   NodeHeight=440
   NodeComment="02 Pulse"
   NodeGuid=8B45B0167CFE444B00D73E8ECAFDAEEB
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_5"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_5"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_5"
      ParameterName="Pulse Speed"
      DefaultValue=2
      SliderMin=0
      SliderMax=8
      Group="02 Pulse"
      Desc="Glow breathing speed (cycles/sec). 0 = steady."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=220
      MaterialExpressionGuid=3AE8B75E8AEE91B1AE7BBA68095B730F
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_5'"
   NodePosX=-2000
   NodePosY=220
   NodeGuid=4B82BA3593D8A6548CC8E7E76AEE20D8
   CustomProperties Pin (PinId=1078D8AF828605BDF167C5A14E032F6C,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_58 D5DCD01AC9655023418AD265FF3D27D6,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_6"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_6"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_6"
      ParameterName="Pulse Floor"
      DefaultValue=0.6
      SliderMin=0
      SliderMax=1
      Group="02 Pulse"
      Desc="Lowest glow level during the pulse (1 = no pulse)."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=420
      MaterialExpressionGuid=A95E5C93B24F9C0E23870DB0BB6E39D7
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_6'"
   NodePosX=-2000
   NodePosY=420
   NodeGuid=7EA7C32B09A25FC05732FB5D5E12A80F
   CustomProperties Pin (PinId=5979B32B58A0245E000178667B9A2BBC,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_63 BF35EFA7816CF2206D21A3CD8181AFEC,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_7"
   Begin Object Class=/Script/Engine.MaterialExpressionComment Name="MaterialExpressionComment_C7"
   End Object
   Begin Object Name="MaterialExpressionComment_C7"
      SizeX=470
      SizeY=440
      Text="03 Edge Detect"
      CommentColor=(R=0.262251,G=0.102242,B=0.023153,A=1.000000)
      MaterialExpressionEditorX=-2080
      MaterialExpressionEditorY=620
      MaterialExpressionGuid=87505889B0E969B15AFB7BC7EA2FD901
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpressionComment="/Script/Engine.MaterialExpressionComment'MaterialExpressionComment_C7'"
   CommentColor=(R=0.262251,G=0.102242,B=0.023153,A=1.000000)
   NodePosX=-2080
   NodePosY=620
   NodeWidth=470
   NodeHeight=440
   NodeComment="03 Edge Detect"
   NodeGuid=E5FCB424FC780820D6AEF5DA16AD026E
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_8"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_8"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_8"
      ParameterName="Edge Threshold"
      DefaultValue=0.04
      SliderMin=0
      SliderMax=0.5
      Group="03 Edge Detect"
      Desc="Below this normalized depth-step the outline is fully off (kills halos)."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=700
      MaterialExpressionGuid=A0CC8B9122957F71629E2705E1B2D5EC
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_8'"
   NodePosX=-2000
   NodePosY=700
   NodeGuid=1298D20D7F1BCC95FC324FF5E45466E5
   CustomProperties Pin (PinId=F190357900AFFDAA8B81CCF636288E05,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_50 026255E939F2708A29391EEB9D8BB7FB,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_9"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_9"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_9"
      ParameterName="Edge Softness"
      DefaultValue=0.2
      SliderMin=0.01
      SliderMax=1
      Group="03 Edge Detect"
      Desc="Upper edge of the smoothstep — raise for a softer, feathered outline."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=900
      MaterialExpressionGuid=1B5BF92D88BE6FE90818B191EB60F957
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_9'"
   NodePosX=-2000
   NodePosY=900
   NodeGuid=4B9E1074F33E6098FEF87A25BE57D968
   CustomProperties Pin (PinId=6B26D61FA80D30B8EACD1270E4EDD53F,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_50 AB79996871618422326B473F2FBB9B8F,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_10"
   Begin Object Class=/Script/Engine.MaterialExpressionComment Name="MaterialExpressionComment_C10"
   End Object
   Begin Object Name="MaterialExpressionComment_C10"
      SizeX=470
      SizeY=440
      Text="04 Interior Fill"
      CommentColor=(R=0.144128,G=0.068478,B=0.023153,A=1.000000)
      MaterialExpressionEditorX=-2080
      MaterialExpressionEditorY=1100
      MaterialExpressionGuid=5417C80CFB777422E854091B54D2CAE3
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpressionComment="/Script/Engine.MaterialExpressionComment'MaterialExpressionComment_C10'"
   CommentColor=(R=0.144128,G=0.068478,B=0.023153,A=1.000000)
   NodePosX=-2080
   NodePosY=1100
   NodeWidth=470
   NodeHeight=440
   NodeComment="04 Interior Fill"
   NodeGuid=E1EB666C12DD7DE3FF2DC519C1FF24E3
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_11"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_11"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_11"
      ParameterName="Fill Opacity"
      DefaultValue=0
      SliderMin=0
      SliderMax=1
      Group="04 Interior Fill"
      Desc="Soft tint over the whole selected object (0 = outline only)."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=1180
      MaterialExpressionGuid=8987916D45192237586B211C5F810C9F
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_11'"
   NodePosX=-2000
   NodePosY=1180
   NodeGuid=C0A49EEBFBBB26F3E4CF2FF25EE4915B
   CustomProperties Pin (PinId=175B629903610EB64524363409BF782E,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_55 8F84B75407D205F974C16E8D3B6D6EDF,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_12"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_12"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_12"
      ParameterName="Selected Depth Limit"
      DefaultValue=10000000
      SliderMin=1000
      SliderMax=100000000
      Group="04 Interior Fill"
      Desc="Pixels whose Custom Depth is nearer than this count as selected (background reads far)."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=1380
      MaterialExpressionGuid=FDB1261F1F1A528B427103BD675B3348
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_12'"
   NodePosX=-2000
   NodePosY=1380
   NodeGuid=013354E4BFCEAD3EFE1B8628C1CBCDFF
   CustomProperties Pin (PinId=5A6CF76EFD419AF630CEFBE7C1CCF556,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_53 9A2B268B793C0441369BCB8E5C21838D,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_13"
   Begin Object Class=/Script/Engine.MaterialExpressionComment Name="MaterialExpressionComment_C13"
   End Object
   Begin Object Name="MaterialExpressionComment_C13"
      SizeX=470
      SizeY=300
      Text="05 Optional Textures"
      CommentColor=(R=0.194618,G=0.107023,B=0.262251,A=1.000000)
      MaterialExpressionEditorX=-2080
      MaterialExpressionEditorY=1600
      MaterialExpressionGuid=AD86F1B7BA25E2A93C4AC214F5CC3C83
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpressionComment="/Script/Engine.MaterialExpressionComment'MaterialExpressionComment_C13'"
   CommentColor=(R=0.194618,G=0.107023,B=0.262251,A=1.000000)
   NodePosX=-2080
   NodePosY=1600
   NodeWidth=470
   NodeHeight=300
   NodeComment="05 Optional Textures"
   NodeGuid=8706CB08A3505909DECF6D6B243D2015
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_14"
   Begin Object Class=/Script/Engine.MaterialExpressionTextureSampleParameter2D Name="MaterialExpressionTextureSampleParameter2D_14"
   End Object
   Begin Object Name="MaterialExpressionTextureSampleParameter2D_14"
      ParameterName="Pattern Mask"
      Group="05 Optional Textures"
      Texture=Texture2D'/Engine/EngineResources/WhiteSquareTexture'
      SamplerType=SAMPLERTYPE_LinearGrayscale
      Desc="Optional grayscale overlay (dashes, scanlines, hazard stripes) multiplied into the highlight. Off until Use Pattern Mask is on."
      MaterialExpressionEditorX=-2000
      MaterialExpressionEditorY=1680
      MaterialExpressionGuid=A7CE6160CF300DF3C46517C75FAB364F
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionTextureSampleParameter2D'MaterialExpressionTextureSampleParameter2D_14'"
   NodePosX=-2000
   NodePosY=1680
   NodeGuid=91FCECCAFFC7254A4700C73A5ED5D3B2
   CustomProperties Pin (PinId=EB359A325E495CC542819E5480E5D97E,PinName="UVs",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=2AFB58CD8351EC203AA6E52364810B02,PinName="ApplyViewMipBias",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=CACB553FBDBC7CB217C68EDBC7483347,PinName="RGB",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=5191C1A7F1D9D95E8E69BF7DC7C8E152,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_67 EB7304B20963E4E959EB2D83A43DC81B,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=25CEE0CDF659AD6EAC89E0EC0AABD127,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=D8F124FCA3F0FABF52F53ED46C70859D,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=0A929969D814BE06AD9988B25E22080D,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=17D33BE96ECDDC9EE06FD106B9357BEE,PinName="RGBA",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_15"
   Begin Object Class=/Script/Engine.MaterialExpressionScreenPosition Name="MaterialExpressionScreenPosition_15"
   End Object
   Begin Object Name="MaterialExpressionScreenPosition_15"
      MaterialExpressionEditorX=-1560
      MaterialExpressionEditorY=480
      MaterialExpressionGuid=A6A8CC31EC8583DABC20DEFFEDDCA452
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScreenPosition'MaterialExpressionScreenPosition_15'"
   NodePosX=-1560
   NodePosY=480
   NodeGuid=F81220A9803B744121F7A74F499D5AD5
   CustomProperties Pin (PinId=ABF61DE94814616C710676061619568C,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_28 AFB825D83EA39A74CF561D17B74BC8B5,MaterialGraphNode_29 4A4D4DAE72B793DFFA82F6C0432E70A5,MaterialGraphNode_30 F8B204F8CBB187BC018538C5841ABB3F,MaterialGraphNode_31 1286C030772AE6222CCA15F124B3E3AA,MaterialGraphNode_51 9095CA36CD0A6DEF916DB14670B92F7B,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_16"
   Begin Object Class=/Script/Engine.MaterialExpressionSceneTexture Name="MaterialExpressionSceneTexture_16"
   End Object
   Begin Object Name="MaterialExpressionSceneTexture_16"
      SceneTextureId=PPI_PostProcessInput0
      bFiltered=False
      MaterialExpressionEditorX=-1560
      MaterialExpressionEditorY=-420
      MaterialExpressionGuid=1EECD5DE3DAFC35427F71CAC66C21A26
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionSceneTexture'MaterialExpressionSceneTexture_16'"
   NodePosX=-1560
   NodePosY=-420
   NodeGuid=41AA43F1F694A014484D23ADDFD3ED7A
   CustomProperties Pin (PinId=F475790A21AA3552946A80762D5FB4F0,PinName="UVs",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=277B3AE6374D67B9DB96D3513B4CDBAB,PinName="Color",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_17 664570EE37BB6A36D7B18BEFEB1E05E0,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=1C8E5CA14623728487B7F69086A6C483,PinName="Size",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=142906E503D9A8AF32F96CCFC40C255E,PinName="InvSize",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_17"
   Begin Object Class=/Script/Engine.MaterialExpressionComponentMask Name="MaterialExpressionComponentMask_17"
   End Object
   Begin Object Name="MaterialExpressionComponentMask_17"
      R=True
      G=True
      B=True
      A=False
      Input=(Expression="/Script/Engine.MaterialExpressionSceneTexture'MaterialGraphNode_16.MaterialExpressionSceneTexture_16'")
      MaterialExpressionEditorX=-1320
      MaterialExpressionEditorY=-420
      MaterialExpressionGuid=B9CEFEAB214C7E786082E7E2F09E32B4
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionComponentMask'MaterialExpressionComponentMask_17'"
   NodePosX=-1320
   NodePosY=-420
   NodeGuid=4F0B37961FE0A578F52F78A6332A8934
   CustomProperties Pin (PinId=664570EE37BB6A36D7B18BEFEB1E05E0,PinName="Input",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_16 277B3AE6374D67B9DB96D3513B4CDBAB,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=E102974884F4F9C1BCDFBB3012824920,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_70 FFB8369A3DF83D2EBCF1475E5496DCEA,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_18"
   Begin Object Class=/Script/Engine.MaterialExpressionSceneTexture Name="MaterialExpressionSceneTexture_18"
   End Object
   Begin Object Name="MaterialExpressionSceneTexture_18"
      SceneTextureId=PPI_CustomDepth
      bFiltered=False
      MaterialExpressionEditorX=-1560
      MaterialExpressionEditorY=200
      MaterialExpressionGuid=662FAB4F3AA1EAAB5E94FC46AC16AF6E
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionSceneTexture'MaterialExpressionSceneTexture_18'"
   NodePosX=-1560
   NodePosY=200
   NodeGuid=284E47D860B626BBDDD5D977F1C57851
   CustomProperties Pin (PinId=83A62BC68D2B81449C8559B45764E86F,PinName="UVs",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=1273BA4A948B6C86F9B096A6A072A256,PinName="Color",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=0B69446CA41BA5E46EBF51F6352FC783,PinName="Size",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=74A0EF30BB7C66396BCF987FEECD88FB,PinName="InvSize",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_19 7D0F96E7F0A0B768B89D4F6982F2C8C8,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_19"
   Begin Object Class=/Script/Engine.MaterialExpressionMultiply Name="MaterialExpressionMultiply_19"
   End Object
   Begin Object Name="MaterialExpressionMultiply_19"
      A=(Expression="/Script/Engine.MaterialExpressionSceneTexture'MaterialGraphNode_18.MaterialExpressionSceneTexture_18'",OutputIndex=2)
      B=(Expression="/Script/Engine.MaterialExpressionScalarParameter'MaterialGraphNode_3.MaterialExpressionScalarParameter_3'")
      MaterialExpressionEditorX=-1320
      MaterialExpressionEditorY=280
      MaterialExpressionGuid=B9765C57C7737833558B544A8337DFF6
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionMultiply'MaterialExpressionMultiply_19'"
   NodePosX=-1320
   NodePosY=280
   NodeGuid=62EEC761EF7D4B3D81C658B6554CF77E
   CustomProperties Pin (PinId=7D0F96E7F0A0B768B89D4F6982F2C8C8,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_18 74A0EF30BB7C66396BCF987FEECD88FB,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=09A2BC3ED007F81444D39A14F73FDD69,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_3 BFAFAD8E505702A7DF1BD3DF9C43F7AB,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=D6002A05BE89CF6FA2993AD0E51E13BE,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_24 DD37EE558FE0E492292BABAEBFB0DEC3,MaterialGraphNode_25 575ED412D478738AC6D261EFE782571C,MaterialGraphNode_26 09A7F86B5C03D4D8615F774226680065,MaterialGraphNode_27 7F2943D41057085DC282F8359EF91E29,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_20"
   Begin Object Class=/Script/Engine.MaterialExpressionConstant2Vector Name="MaterialExpressionConstant2Vector_20"
   End Object
   Begin Object Name="MaterialExpressionConstant2Vector_20"
      R=1
      G=1
      MaterialExpressionEditorX=-1320
      MaterialExpressionEditorY=560
      MaterialExpressionGuid=31FEFB91201D7B878C80976B28315796
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionConstant2Vector'MaterialExpressionConstant2Vector_20'"
   NodePosX=-1320
   NodePosY=560
   NodeGuid=15A5F6199776E8892CAAA59BE3939C99
   CustomProperties Pin (PinId=C8541D0A7D6B5758B058BC7A55EAC2D4,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_24 5EA5B2288465FACFD0C1D19E5561C3FA,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_21"
   Begin Object Class=/Script/Engine.MaterialExpressionConstant2Vector Name="MaterialExpressionConstant2Vector_21"
   End Object
   Begin Object Name="MaterialExpressionConstant2Vector_21"
      R=-1
      G=-1
      MaterialExpressionEditorX=-1320
      MaterialExpressionEditorY=700
      MaterialExpressionGuid=607C9C8A2D71A88C96A1FF0162B4E98D
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionConstant2Vector'MaterialExpressionConstant2Vector_21'"
   NodePosX=-1320
   NodePosY=700
   NodeGuid=C2B033E325559A6A409EEB090B14E692
   CustomProperties Pin (PinId=069159D931B6BEA69B019716BD0EF82D,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_25 01C33CD81E5DA9678BDA403BD2ACF20B,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_22"
   Begin Object Class=/Script/Engine.MaterialExpressionConstant2Vector Name="MaterialExpressionConstant2Vector_22"
   End Object
   Begin Object Name="MaterialExpressionConstant2Vector_22"
      R=-1
      G=1
      MaterialExpressionEditorX=-1320
      MaterialExpressionEditorY=840
      MaterialExpressionGuid=850A1BCBDE565A5ABBC631857BDAEE91
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionConstant2Vector'MaterialExpressionConstant2Vector_22'"
   NodePosX=-1320
   NodePosY=840
   NodeGuid=2D2BDC1C2A64EA5EF4F316C99FA54E40
   CustomProperties Pin (PinId=761A7AAA040D46348BC69DB1102E0910,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_26 CA6102B5699E7BAAB1E42CA6D5906C40,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_23"
   Begin Object Class=/Script/Engine.MaterialExpressionConstant2Vector Name="MaterialExpressionConstant2Vector_23"
   End Object
   Begin Object Name="MaterialExpressionConstant2Vector_23"
      R=1
      G=-1
      MaterialExpressionEditorX=-1320
      MaterialExpressionEditorY=980
      MaterialExpressionGuid=7172D17024FB25B5BEDBCAD763C9BB13
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionConstant2Vector'MaterialExpressionConstant2Vector_23'"
   NodePosX=-1320
   NodePosY=980
   NodeGuid=CCB84A3B9CBCB98EEB6AEC7A67DDF1A3
   CustomProperties Pin (PinId=A3BC6D4A8F565DB4B581C547F5B196C3,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_27 E215162E1425B526CAA1510E154ADB5B,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_24"
   Begin Object Class=/Script/Engine.MaterialExpressionMultiply Name="MaterialExpressionMultiply_24"
   End Object
   Begin Object Name="MaterialExpressionMultiply_24"
      A=(Expression="/Script/Engine.MaterialExpressionMultiply'MaterialGraphNode_19.MaterialExpressionMultiply_19'")
      B=(Expression="/Script/Engine.MaterialExpressionConstant2Vector'MaterialGraphNode_20.MaterialExpressionConstant2Vector_20'")
      MaterialExpressionEditorX=-1080
      MaterialExpressionEditorY=560
      MaterialExpressionGuid=566B0CB5EB5B2984E54CB7C06374CC07
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionMultiply'MaterialExpressionMultiply_24'"
   NodePosX=-1080
   NodePosY=560
   NodeGuid=DDABAD4B3CB918B88BEB8E6DD685264D
   CustomProperties Pin (PinId=DD37EE558FE0E492292BABAEBFB0DEC3,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_19 D6002A05BE89CF6FA2993AD0E51E13BE,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=5EA5B2288465FACFD0C1D19E5561C3FA,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_20 C8541D0A7D6B5758B058BC7A55EAC2D4,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=9E082D598208344C69D43A4238D86847,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_28 1511CC36856C176530C8881EA8C3D904,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_25"
   Begin Object Class=/Script/Engine.MaterialExpressionMultiply Name="MaterialExpressionMultiply_25"
   End Object
   Begin Object Name="MaterialExpressionMultiply_25"
      A=(Expression="/Script/Engine.MaterialExpressionMultiply'MaterialGraphNode_19.MaterialExpressionMultiply_19'")
      B=(Expression="/Script/Engine.MaterialExpressionConstant2Vector'MaterialGraphNode_21.MaterialExpressionConstant2Vector_21'")
      MaterialExpressionEditorX=-1080
      MaterialExpressionEditorY=700
      MaterialExpressionGuid=1E64576650AE4C62D0B11E49F45CFD17
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionMultiply'MaterialExpressionMultiply_25'"
   NodePosX=-1080
   NodePosY=700
   NodeGuid=8CDEEC596BF64054CDDA235090F8B0DE
   CustomProperties Pin (PinId=575ED412D478738AC6D261EFE782571C,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_19 D6002A05BE89CF6FA2993AD0E51E13BE,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=01C33CD81E5DA9678BDA403BD2ACF20B,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_21 069159D931B6BEA69B019716BD0EF82D,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=5358A3792C7A06E5D922B676F0A3694E,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_29 AF8D611A3962EA2D72D23EBAFE3426AA,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_26"
   Begin Object Class=/Script/Engine.MaterialExpressionMultiply Name="MaterialExpressionMultiply_26"
   End Object
   Begin Object Name="MaterialExpressionMultiply_26"
      A=(Expression="/Script/Engine.MaterialExpressionMultiply'MaterialGraphNode_19.MaterialExpressionMultiply_19'")
      B=(Expression="/Script/Engine.MaterialExpressionConstant2Vector'MaterialGraphNode_22.MaterialExpressionConstant2Vector_22'")
      MaterialExpressionEditorX=-1080
      MaterialExpressionEditorY=840
      MaterialExpressionGuid=FD22C83B76639F26761C080BB35C34F7
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionMultiply'MaterialExpressionMultiply_26'"
   NodePosX=-1080
   NodePosY=840
   NodeGuid=61FC32849072A7BD0B0BEDBC65F0F8A0
   CustomProperties Pin (PinId=09A7F86B5C03D4D8615F774226680065,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_19 D6002A05BE89CF6FA2993AD0E51E13BE,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=CA6102B5699E7BAAB1E42CA6D5906C40,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_22 761A7AAA040D46348BC69DB1102E0910,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=B7B525E6226B4BABDC00A7422F0D151A,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_30 F3FBB9DF0B3AFDFE545AE0CBD8C6F661,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_27"
   Begin Object Class=/Script/Engine.MaterialExpressionMultiply Name="MaterialExpressionMultiply_27"
   End Object
   Begin Object Name="MaterialExpressionMultiply_27"
      A=(Expression="/Script/Engine.MaterialExpressionMultiply'MaterialGraphNode_19.MaterialExpressionMultiply_19'")
      B=(Expression="/Script/Engine.MaterialExpressionConstant2Vector'MaterialGraphNode_23.MaterialExpressionConstant2Vector_23'")
      MaterialExpressionEditorX=-1080
      MaterialExpressionEditorY=980
      MaterialExpressionGuid=BF8A3D8D7CB1BF766C2C7D1BF11E6388
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionMultiply'MaterialExpressionMultiply_27'"
   NodePosX=-1080
   NodePosY=980
   NodeGuid=75E08A16533399BE309EE23400C154CD
   CustomProperties Pin (PinId=7F2943D41057085DC282F8359EF91E29,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_19 D6002A05BE89CF6FA2993AD0E51E13BE,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=E215162E1425B526CAA1510E154ADB5B,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_23 A3BC6D4A8F565DB4B581C547F5B196C3,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=60003867CB5854A7E0EB89EDFE479588,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_31 8967C2DC42D0200015ED4D85F2F737BD,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_28"
   Begin Object Class=/Script/Engine.MaterialExpressionAdd Name="MaterialExpressionAdd_28"
   End Object
   Begin Object Name="MaterialExpressionAdd_28"
      A=(Expression="/Script/Engine.MaterialExpressionScreenPosition'MaterialGraphNode_15.MaterialExpressionScreenPosition_15'")
      B=(Expression="/Script/Engine.MaterialExpressionMultiply'MaterialGraphNode_24.MaterialExpressionMultiply_24'")
      MaterialExpressionEditorX=-880
      MaterialExpressionEditorY=560
      MaterialExpressionGuid=12D2162846EC1723F956DB7062B40102
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionAdd'MaterialExpressionAdd_28'"
   NodePosX=-880
   NodePosY=560
   NodeGuid=2F92CD7B4EE9EDCAD1DAF00B647900E1
   CustomProperties Pin (PinId=AFB825D83EA39A74CF561D17B74BC8B5,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_15 ABF61DE94814616C710676061619568C,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=1511CC36856C176530C8881EA8C3D904,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_24 9E082D598208344C69D43A4238D86847,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=373F9365BD4977240BD5A030C429D95E,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_32 00902314FD49D95ED96FE7FEA6CEAA25,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_29"
   Begin Object Class=/Script/Engine.MaterialExpressionAdd Name="MaterialExpressionAdd_29"
   End Object
   Begin Object Name="MaterialExpressionAdd_29"
      A=(Expression="/Script/Engine.MaterialExpressionScreenPosition'MaterialGraphNode_15.MaterialExpressionScreenPosition_15'")
      B=(Expression="/Script/Engine.MaterialExpressionMultiply'MaterialGraphNode_25.MaterialExpressionMultiply_25'")
      MaterialExpressionEditorX=-880
      MaterialExpressionEditorY=700
      MaterialExpressionGuid=8D29DF86E1FE695D8BD8FC9D31B1C0B1
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionAdd'MaterialExpressionAdd_29'"
   NodePosX=-880
   NodePosY=700
   NodeGuid=A0E1DA09AD48804FFE59327174C30364
   CustomProperties Pin (PinId=4A4D4DAE72B793DFFA82F6C0432E70A5,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_15 ABF61DE94814616C710676061619568C,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=AF8D611A3962EA2D72D23EBAFE3426AA,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_25 5358A3792C7A06E5D922B676F0A3694E,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=FA213808A26A2B1CB26425EEF53707E7,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_33 077546FAD02D3610FD5692C31F4F8264,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_30"
   Begin Object Class=/Script/Engine.MaterialExpressionAdd Name="MaterialExpressionAdd_30"
   End Object
   Begin Object Name="MaterialExpressionAdd_30"
      A=(Expression="/Script/Engine.MaterialExpressionScreenPosition'MaterialGraphNode_15.MaterialExpressionScreenPosition_15'")
      B=(Expression="/Script/Engine.MaterialExpressionMultiply'MaterialGraphNode_26.MaterialExpressionMultiply_26'")
      MaterialExpressionEditorX=-880
      MaterialExpressionEditorY=840
      MaterialExpressionGuid=59234384A4A354A2D6B92E292CBDEBC4
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionAdd'MaterialExpressionAdd_30'"
   NodePosX=-880
   NodePosY=840
   NodeGuid=9E0E86CA071D824797D2ECED7AC1B118
   CustomProperties Pin (PinId=F8B204F8CBB187BC018538C5841ABB3F,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_15 ABF61DE94814616C710676061619568C,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=F3FBB9DF0B3AFDFE545AE0CBD8C6F661,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_26 B7B525E6226B4BABDC00A7422F0D151A,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=864783891EBEDA3252284450ED7E10AD,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_34 87F9BF671B83F7B4D1278EE0B4187CD3,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_31"
   Begin Object Class=/Script/Engine.MaterialExpressionAdd Name="MaterialExpressionAdd_31"
   End Object
   Begin Object Name="MaterialExpressionAdd_31"
      A=(Expression="/Script/Engine.MaterialExpressionScreenPosition'MaterialGraphNode_15.MaterialExpressionScreenPosition_15'")
      B=(Expression="/Script/Engine.MaterialExpressionMultiply'MaterialGraphNode_27.MaterialExpressionMultiply_27'")
      MaterialExpressionEditorX=-880
      MaterialExpressionEditorY=980
      MaterialExpressionGuid=2958C9CE7CB743BBB52E68FA4E95D49B
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionAdd'MaterialExpressionAdd_31'"
   NodePosX=-880
   NodePosY=980
   NodeGuid=8F776A6BF900355FB0D43DB43F4ED0F9
   CustomProperties Pin (PinId=1286C030772AE6222CCA15F124B3E3AA,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_15 ABF61DE94814616C710676061619568C,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=8967C2DC42D0200015ED4D85F2F737BD,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_27 60003867CB5854A7E0EB89EDFE479588,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=6C3E87221DD2D2EE091426FDF21AA5A5,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_35 A8EAF997557253631D6F15055FE4DDF1,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_32"
   Begin Object Class=/Script/Engine.MaterialExpressionSceneTexture Name="MaterialExpressionSceneTexture_32"
   End Object
   Begin Object Name="MaterialExpressionSceneTexture_32"
      SceneTextureId=PPI_CustomDepth
      bFiltered=False
      Coordinates=(Expression="/Script/Engine.MaterialExpressionAdd'MaterialGraphNode_28.MaterialExpressionAdd_28'")
      MaterialExpressionEditorX=-640
      MaterialExpressionEditorY=540
      MaterialExpressionGuid=D994DE0C315328BB10BC6CE497CDBD06
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionSceneTexture'MaterialExpressionSceneTexture_32'"
   NodePosX=-640
   NodePosY=540
   NodeGuid=2AF146539DC0551C979227DA155A43F6
   CustomProperties Pin (PinId=00902314FD49D95ED96FE7FEA6CEAA25,PinName="UVs",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_28 373F9365BD4977240BD5A030C429D95E,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=1A4AEAF77ACBF422A1116FC96CDA64A6,PinName="Color",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_36 4E1EEA5E7960AECDD93CD0C3A1D43581,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=573D7BE100F0BDA541DDAF766A68D921,PinName="Size",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=77CA3835FB393033BF23AC004143E712,PinName="InvSize",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_33"
   Begin Object Class=/Script/Engine.MaterialExpressionSceneTexture Name="MaterialExpressionSceneTexture_33"
   End Object
   Begin Object Name="MaterialExpressionSceneTexture_33"
      SceneTextureId=PPI_CustomDepth
      bFiltered=False
      Coordinates=(Expression="/Script/Engine.MaterialExpressionAdd'MaterialGraphNode_29.MaterialExpressionAdd_29'")
      MaterialExpressionEditorX=-640
      MaterialExpressionEditorY=680
      MaterialExpressionGuid=F6F7BCFE30154ECC2497F70260B3B72C
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionSceneTexture'MaterialExpressionSceneTexture_33'"
   NodePosX=-640
   NodePosY=680
   NodeGuid=221B9852C3FE2AC7875E45616A210190
   CustomProperties Pin (PinId=077546FAD02D3610FD5692C31F4F8264,PinName="UVs",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_29 FA213808A26A2B1CB26425EEF53707E7,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=78B021FA4F5CA12CDE853EC8DEB3D7F8,PinName="Color",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_37 B7D6C5D205BC06AB9AC3C11BD7A6C12A,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=3B9965AE760B7818B17DB5FA0A13CA16,PinName="Size",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=EC649F57D101AD761BCFD063CA80C79B,PinName="InvSize",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_34"
   Begin Object Class=/Script/Engine.MaterialExpressionSceneTexture Name="MaterialExpressionSceneTexture_34"
   End Object
   Begin Object Name="MaterialExpressionSceneTexture_34"
      SceneTextureId=PPI_CustomDepth
      bFiltered=False
      Coordinates=(Expression="/Script/Engine.MaterialExpressionAdd'MaterialGraphNode_30.MaterialExpressionAdd_30'")
      MaterialExpressionEditorX=-640
      MaterialExpressionEditorY=820
      MaterialExpressionGuid=5277158C35B9C7B573357C3B6C17B80A
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionSceneTexture'MaterialExpressionSceneTexture_34'"
   NodePosX=-640
   NodePosY=820
   NodeGuid=5BF220070CB5A5B8EC6A30C5E26A948A
   CustomProperties Pin (PinId=87F9BF671B83F7B4D1278EE0B4187CD3,PinName="UVs",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_30 864783891EBEDA3252284450ED7E10AD,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=A775DE5442EA3BDA5081F62007F209BA,PinName="Color",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_38 345689895622B1A5273B37DB7BDADF6B,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=2D99AD951EF90210DA969BC4336D578C,PinName="Size",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=3CB2520E06A752AEAB7172E51F4C0CF0,PinName="InvSize",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_35"
   Begin Object Class=/Script/Engine.MaterialExpressionSceneTexture Name="MaterialExpressionSceneTexture_35"
   End Object
   Begin Object Name="MaterialExpressionSceneTexture_35"
      SceneTextureId=PPI_CustomDepth
      bFiltered=False
      Coordinates=(Expression="/Script/Engine.MaterialExpressionAdd'MaterialGraphNode_31.MaterialExpressionAdd_31'")
      MaterialExpressionEditorX=-640
      MaterialExpressionEditorY=960
      MaterialExpressionGuid=379212B1603523A5D59EC78BCB1146B7
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionSceneTexture'MaterialExpressionSceneTexture_35'"
   NodePosX=-640
   NodePosY=960
   NodeGuid=43F7AED91F54A681715C31C03092F7EC
   CustomProperties Pin (PinId=A8EAF997557253631D6F15055FE4DDF1,PinName="UVs",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_31 6C3E87221DD2D2EE091426FDF21AA5A5,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=FE8FF6D9C1107B1EA3B76C7265F605E9,PinName="Color",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_39 44A3E3238E0A6074ED074017F0FF4F8B,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=690BA599EFEFD9F0A638F8BECC6E547B,PinName="Size",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=8638CBD8327CD2E6AB21860806FEDB1A,PinName="InvSize",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_36"
   Begin Object Class=/Script/Engine.MaterialExpressionComponentMask Name="MaterialExpressionComponentMask_36"
   End Object
   Begin Object Name="MaterialExpressionComponentMask_36"
      R=True
      G=False
      B=False
      A=False
      Input=(Expression="/Script/Engine.MaterialExpressionSceneTexture'MaterialGraphNode_32.MaterialExpressionSceneTexture_32'")
      MaterialExpressionEditorX=-420
      MaterialExpressionEditorY=540
      MaterialExpressionGuid=AFD1BE2F3B80AEBFD3AAAA9813B10FC9
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionComponentMask'MaterialExpressionComponentMask_36'"
   NodePosX=-420
   NodePosY=540
   NodeGuid=C133A0A263C5CDF30A7174AFF1310CDA
   CustomProperties Pin (PinId=4E1EEA5E7960AECDD93CD0C3A1D43581,PinName="Input",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_32 1A4AEAF77ACBF422A1116FC96CDA64A6,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=0CB9DCBF7D3E5E940D10DB006230465A,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_40 1F728FF5900628147DD4380F9E50EBF5,MaterialGraphNode_45 906B6B37B665C0FC15C15869C16FC075,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_37"
   Begin Object Class=/Script/Engine.MaterialExpressionComponentMask Name="MaterialExpressionComponentMask_37"
   End Object
   Begin Object Name="MaterialExpressionComponentMask_37"
      R=True
      G=False
      B=False
      A=False
      Input=(Expression="/Script/Engine.MaterialExpressionSceneTexture'MaterialGraphNode_33.MaterialExpressionSceneTexture_33'")
      MaterialExpressionEditorX=-420
      MaterialExpressionEditorY=680
      MaterialExpressionGuid=A0BE4DE937AF38C3A86ED3E651991E95
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionComponentMask'MaterialExpressionComponentMask_37'"
   NodePosX=-420
   NodePosY=680
   NodeGuid=0F01DA678BCABFCCBC708B61CB69EFF9
   CustomProperties Pin (PinId=B7D6C5D205BC06AB9AC3C11BD7A6C12A,PinName="Input",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_33 78B021FA4F5CA12CDE853EC8DEB3D7F8,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=F49CA096DB4733C9AB2755352500C8F1,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_40 5E2D4B92CD984214D02B40E39978D194,MaterialGraphNode_45 E039A02A7E47BE076C9F4300B9EDCEAC,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_38"
   Begin Object Class=/Script/Engine.MaterialExpressionComponentMask Name="MaterialExpressionComponentMask_38"
   End Object
   Begin Object Name="MaterialExpressionComponentMask_38"
      R=True
      G=False
      B=False
      A=False
      Input=(Expression="/Script/Engine.MaterialExpressionSceneTexture'MaterialGraphNode_34.MaterialExpressionSceneTexture_34'")
      MaterialExpressionEditorX=-420
      MaterialExpressionEditorY=820
      MaterialExpressionGuid=302EE9D869EE0D2E7B1E0B1ACE159069
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionComponentMask'MaterialExpressionComponentMask_38'"
   NodePosX=-420
   NodePosY=820
   NodeGuid=2811B32817E977E462EA717AA0D585E4
   CustomProperties Pin (PinId=345689895622B1A5273B37DB7BDADF6B,PinName="Input",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_34 A775DE5442EA3BDA5081F62007F209BA,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=44F84A733022312D257A945EAE8DAE79,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_41 D2FE1014A0D94A58B7BBB1A8229C5FD6,MaterialGraphNode_46 004F6DB351AF5955591F27D17D84B616,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_39"
   Begin Object Class=/Script/Engine.MaterialExpressionComponentMask Name="MaterialExpressionComponentMask_39"
   End Object
   Begin Object Name="MaterialExpressionComponentMask_39"
      R=True
      G=False
      B=False
      A=False
      Input=(Expression="/Script/Engine.MaterialExpressionSceneTexture'MaterialGraphNode_35.MaterialExpressionSceneTexture_35'")
      MaterialExpressionEditorX=-420
      MaterialExpressionEditorY=960
      MaterialExpressionGuid=E7F467D18346E1B47F9910F9AB045A3D
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionComponentMask'MaterialExpressionComponentMask_39'"
   NodePosX=-420
   NodePosY=960
   NodeGuid=191619FD749A6D66DCC9A585292A384A
   CustomProperties Pin (PinId=44A3E3238E0A6074ED074017F0FF4F8B,PinName="Input",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_35 FE8FF6D9C1107B1EA3B76C7265F605E9,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=048687FBE4C4E61796F791A677EAA0EA,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_41 62534960CCE5AE7FB93FA3D1F1860926,MaterialGraphNode_46 126FB470389F840BD6764F98BBC5AAB5,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_40"
   Begin Object Class=/Script/Engine.MaterialExpressionSubtract Name="MaterialExpressionSubtract_40"
   End Object
   Begin Object Name="MaterialExpressionSubtract_40"
      A=(Expression="/Script/Engine.MaterialExpressionComponentMask'MaterialGraphNode_36.MaterialExpressionComponentMask_36'")
      B=(Expression="/Script/Engine.MaterialExpressionComponentMask'MaterialGraphNode_37.MaterialExpressionComponentMask_37'")
      MaterialExpressionEditorX=-200
      MaterialExpressionEditorY=560
      MaterialExpressionGuid=1FE1327B61B5672FA741572E851DF9FB
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionSubtract'MaterialExpressionSubtract_40'"
   NodePosX=-200
   NodePosY=560
   NodeGuid=4BE203AAD40947FA5F2551512DCD921E
   CustomProperties Pin (PinId=1F728FF5900628147DD4380F9E50EBF5,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_36 0CB9DCBF7D3E5E940D10DB006230465A,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=5E2D4B92CD984214D02B40E39978D194,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_37 F49CA096DB4733C9AB2755352500C8F1,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=F1D0A5A33085AB872E38F08527EA50D9,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_42 735F47F0C2E9EC007E419D2C3BD64B4A,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_41"
   Begin Object Class=/Script/Engine.MaterialExpressionSubtract Name="MaterialExpressionSubtract_41"
   End Object
   Begin Object Name="MaterialExpressionSubtract_41"
      A=(Expression="/Script/Engine.MaterialExpressionComponentMask'MaterialGraphNode_38.MaterialExpressionComponentMask_38'")
      B=(Expression="/Script/Engine.MaterialExpressionComponentMask'MaterialGraphNode_39.MaterialExpressionComponentMask_39'")
      MaterialExpressionEditorX=-200
      MaterialExpressionEditorY=900
      MaterialExpressionGuid=3CE9D805CDCA148AC10E634774AB911D
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionSubtract'MaterialExpressionSubtract_41'"
   NodePosX=-200
   NodePosY=900
   NodeGuid=20F96CC1B820726F5237206EA745AD0F
   CustomProperties Pin (PinId=D2FE1014A0D94A58B7BBB1A8229C5FD6,PinName="A",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_38 44F84A733022312D257A945EAE8DAE79,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=62534960CCE5AE7FB93FA3D1F1860926,PinName="B",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_39 048687FBE4C4E61796F791A677EAA0EA,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=B6E977C2CE27FD1246BA988CEB796628,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_43 722F380900AC9458F4021163594BB15B,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_42"
   Begin Object Class=/Script/Engine.MaterialExpressionAbs Name="MaterialExpressionAbs_42"
   End Object
   Begin Object Name="MaterialExpressionAbs_42"
      Input=(Expression="/Script/Engine.MaterialExpressionSubtract'MaterialGraphNode_40.MaterialExpressionSubtract_40'")
      MaterialExpressionEditorX=0
      MaterialExpressionEditorY=560
      MaterialExpressionGuid=AA5C433ADBA89FCAA90D2EB0058800F1
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionAbs'MaterialExpressionAbs_42'"
   NodePosX=0
   NodePosY=560
   NodeGuid=FBAD9DF594CDAB8B65BB896A87CB9251
   CustomProperties Pin (PinId=735F47F0C2E9EC007E419D2C3BD64B4A,PinName="Input",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_40 F1D0A5A33085AB872E38F08527EA50D9,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=B32BA3FAF7CE936F26B0C75A77102D0D,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_44 BFB6011A777E07A6B78DA1BFB8CDC6D2,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_43"
   Begin Object Class=/Script/Engine.MaterialExpressionAbs Name="MaterialExpressionAbs_43"
   End Object
   Begin Object Name="MaterialExpressionAbs_43"
      Input=(Expression="/Script/Engine.MaterialExpressionSubtract'MaterialGraphNode_41.MaterialExpressionSubtract_41'")
      MaterialExpressionEditorX=0
      MaterialExpressionEditorY=900
      MaterialExpressionGuid=AE3B66413198FB097A6396CD686F3451
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.M_SelectionHighlight'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionAbs'MaterialExpressionAbs_43'"
   NodePosX=0
   NodePosY=900
   NodeGuid=D9A30BA2A1130D77A835C8099B6F844C
   CustomProperties Pin (PinId=722F380900AC9458F4021163594BB15B,PinName="Input",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.Pin
…

Source truncated for rendering. Use Copy to grab the full 174 KB.

Nodes: Multiply (x11), ScalarParameter (x8), SceneTexture (x7), Add (x6), Comment (x6), ComponentMask (x6), Constant2Vector (x4), Max (x4), Subtract (x3), Abs (x2), Constant (x2), LinearInterpolate (x2), Saturate (x2), Divide, Material, ScreenPosition, Sine, SmoothStep, StaticSwitchParameter, TextureSampleParameter2D, Time, VectorParameter

more from @hazesee all

Stylized Character

@hazeUE 5.6+

Ground Blend

@hazeUE 5.6+

Wobble

@hazeUE 5.6+

More like this

browse all

Glow Ring

@hazeUE 5.6+

Stylized Character

@hazeUE 5.6+

Ground Blend

@hazeUE 5.6+

Selection Highlight

@hazefounder
Nanite-friendly
UE 5.6UE 5.7
0
license

CC0 1.0: Public Domain

Public domain: use it however you like, no credit required.

dependencies

Zero dependencies

Pastes and works in any UE 5.3+ project. No textures, no material functions, no MPCs.

tags
#procedural#post-process#selection#outline#highlight#hover#edge-detect#custom-depth
ue compatibility
UE 5.3UE 5.4UE 5.5UE 5.6UE 5.7

Details

Last update
3 hours ago
Published
3 hours ago
Nodes
72
