Force Field
preview · 1 / 4

Description

Death Stranding-flavored sci-fi force shield, material-only. Warm amber soft body, drifting concentric scanner rings, hot orange knife-edge rim with a wide outer halo, hot contact glow where the shield meets geometry, refractive distortion at the edges, four-slot world-space impact ripples (cyan-white rings with burst and distortion spike on hit), bottom-up activation/shutdown wipe with a noise-broken leading edge, damage state that punches opacity holes and shifts color toward red, and a subtle idle breathing pulse. 72 art-directable parameters across 12 groups. ** Setup** In the Material asset's Details panel, set:

  • Shading Model — Unlit
  • Blend Mode — Translucent (or TranslucentColoredTransmittance under Substrate)
  • Two Sided — On
  • Translucency Lighting Mode — Surface ForwardShading
  • Refraction Method — Pixel Normal Offset
  • Output Velocity — Off

Then:

  • On the target mesh: open the static mesh asset → Nanite Settings → uncheck Enable Nanite Support. Nanite + Translucent breaks geometry.
  • Make sure the mesh is oriented with local +Z as up — the bottom-up activation reveal and contact glow rely on it.
  • Create a Material Instance for tuning.
material graph

Preview only · open in editor for full material editing

Want this graph on your blog or forum?

1 comment

Sign in to join the discussion.

source
View T3D source (608 KB)expand
Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_0"
   NodePosX=-4440
   NodePosY=-3700
   NodeWidth=540
   NodeHeight=820
   NodeComment="00 Body"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=7D7C782629E76B89AB75554C994C8429
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_1"
   NodePosX=-4440
   NodePosY=-2880
   NodeWidth=540
   NodeHeight=1180
   NodeComment="01 Rim"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=37A506B9A525A5D4A3A2D1266DDBFECC
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_2"
   NodePosX=-4440
   NodePosY=-1680
   NodeWidth=540
   NodeHeight=640
   NodeComment="02 Intersection"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=6F81E0BCB1FDA08D842EABC53CCD32A5
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_3"
   NodePosX=-4440
   NodePosY=-1020
   NodeWidth=540
   NodeHeight=1180
   NodeComment="03 Scanner Rings"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=9C6A9878BD2009DF558DF807C0B3D295
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_4"
   NodePosX=-3840
   NodePosY=-3700
   NodeWidth=540
   NodeHeight=2080
   NodeComment="04 Energy Flow + Pulse Rings + Scanlines"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=E585909E25185CEB063C3C93DA6CF1F5
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_5"
   NodePosX=-3840
   NodePosY=-1600
   NodeWidth=540
   NodeHeight=1000
   NodeComment="05 Distortion / Refraction"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=938308032B6096543F2C9928C81E2E76
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_6"
   NodePosX=-3240
   NodePosY=-3700
   NodeWidth=540
   NodeHeight=2980
   NodeComment="06 Impacts (4 Slots)"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=6D07B69E71D6B93C673D5746AA54941A
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_7"
   NodePosX=-3240
   NodePosY=-880
   NodeWidth=540
   NodeHeight=1360
   NodeComment="07 Activation / Shutdown"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=C994D9B65083EDB575F8384126EC0CE5
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_8"
   NodePosX=-2640
   NodePosY=-3700
   NodeWidth=540
   NodeHeight=1720
   NodeComment="08 Damage"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=ECCE17C8EA085F11553ACDB022B6FCC0
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_9"
   NodePosX=-2640
   NodePosY=-1960
   NodeWidth=540
   NodeHeight=640
   NodeComment="09 Fade"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=21BF221FABFF5D0BB6E32CCAC6C9E764
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_10"
   NodePosX=-2640
   NodePosY=-1300
   NodeWidth=540
   NodeHeight=460
   NodeComment="10 Breathing (Idle)"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=ED9BB2297131995DF265F6191BED77EE
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_11"
   NodePosX=-2640
   NodePosY=-820
   NodeWidth=540
   NodeHeight=280
   NodeComment="11 Optional WPO Bounce"
   CommentColor=(R=0.104616,G=0.327778,B=0.665387,A=1.000000)
   NodeGuid=5CCD0CFE4ECF8A82938C9F9E06565CBA
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_12"
   NodePosX=-1840
   NodePosY=-3700
   NodeWidth=320
   NodeHeight=1480
   NodeComment="Inputs"
   CommentColor=(R=1.000000,G=0.194618,B=0.445201,A=1.000000)
   NodeGuid=5A362BD52950470AF4F5DA3802A8CE7B
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_13"
   NodePosX=-1380
   NodePosY=-3700
   NodeWidth=560
   NodeHeight=1180
   NodeComment="Coord Setup (LocalUpDot, ObjDist, UV)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=26D49606F09877A2213A76C8B32CE136
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_14"
   NodePosX=-660
   NodePosY=-3700
   NodeWidth=1000
   NodeHeight=2200
   NodeComment="Shield Engine (Custom HLSL — 4-slot impact + activation + damage)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=63DEF3DFC0B5C5BF674C99A9729BD751
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_15"
   NodePosX=560
   NodePosY=-3700
   NodeWidth=320
   NodeHeight=780
   NodeComment="Split Impact Output"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=75F986604AF14145B57A71CDFCA6D99C
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_16"
   NodePosX=920
   NodePosY=-3700
   NodeWidth=1320
   NodeHeight=440
   NodeComment="Body Fresnel + Color (BodyColor × Bright × Fresnel × Breathe)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=3887DDC557DAAD0B6FFA564E0B4B741C
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_17"
   NodePosX=920
   NodePosY=-3220
   NodeWidth=920
   NodeHeight=320
   NodeComment="Rim Fresnel (Sharp Knife Edge)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=453A0C0924C23D71FEAA5D43A5BF4C31
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_18"
   NodePosX=920
   NodePosY=-2860
   NodeWidth=920
   NodeHeight=320
   NodeComment="Outer Halo (Wide Fresnel)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=5E1FC170880180729CE49AB6F7A94A96
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_19"
   NodePosX=920
   NodePosY=-2500
   NodeWidth=1100
   NodeHeight=320
   NodeComment="Intersection Contact Glow (DepthFade × Color × Brightness)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=C47CF10443A56A216EBC14611AB6563E
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_20"
   NodePosX=920
   NodePosY=-2140
   NodeWidth=1480
   NodeHeight=440
   NodeComment="Scanner Rings (LocalDist × Freq − Time × Speed → Sin → Sharp)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=A6480C251AF085D47DC006737898FCBC
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_21"
   NodePosX=920
   NodePosY=-1680
   NodeWidth=1660
   NodeHeight=320
   NodeComment="Scanner Emissive (sharp × Bright × Color × FresnelMask × (1 + PatternBoost))"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=214AE1A2A204799E6B59907901AB5555
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_22"
   NodePosX=920
   NodePosY=-1320
   NodeWidth=1480
   NodeHeight=320
   NodeComment="Energy Flow (Panner → NoiseTex → Strength → 1+modulation)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=D8C6CA81F0A59E4972E121FA9BDD2994
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_23"
   NodePosX=920
   NodePosY=-960
   NodeWidth=1480
   NodeHeight=320
   NodeComment="Body Pulse Rings (Dist × Freq − Time × Speed → Sin)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=95EA7682916EFE4F5ACDBAF6CCE815D4
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_24"
   NodePosX=920
   NodePosY=-600
   NodeWidth=1480
   NodeHeight=320
   NodeComment="Scanlines (LocalPos.Z × Freq − Time × Speed → Sin)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=348697596D9E0D1D0E53B6C3146DEBE2
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_25"
   NodePosX=920
   NodePosY=-240
   NodeWidth=1100
   NodeHeight=320
   NodeComment="Breathing (Sin(Time × Rate) × Depth + 1)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=3B4E4B5D254488B6B92C0ACDC7CA7C75
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_26"
   NodePosX=920
   NodePosY=100
   NodeWidth=1660
   NodeHeight=440
   NodeComment="Distortion Normal (Panned NoiseTex twice → Append → Normalize)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=7C7D676FE92651182497E817E695216B
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_27"
   NodePosX=920
   NodePosY=580
   NodeWidth=1900
   NodeHeight=440
   NodeComment="Refraction Strength (Base + EdgeFresnel × Boost + Impact × Boost + Damage × Boost)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=8882E56187C38AE19E8DFAF828459C03
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_28"
   NodePosX=920
   NodePosY=1060
   NodeWidth=1320
   NodeHeight=320
   NodeComment="Impact Emissive (Ring + Burst) × Bright × Color"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=E4126547EA10F65B71715515BCBCB8E6
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_29"
   NodePosX=920
   NodePosY=1400
   NodeWidth=1100
   NodeHeight=320
   NodeComment="Activation Edge Emissive (RevealEdge × Bright × Color)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=AD4EA74EBEF9F7A533756C242C0A622B
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_30"
   NodePosX=920
   NodePosY=1740
   NodeWidth=1480
   NodeHeight=320
   NodeComment="Damage Flicker (Panned NoiseTex × DamageAmount × Strength)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=5BF53E2F5802D9026A1FB7D11A820888
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_31"
   NodePosX=920
   NodePosY=2080
   NodeWidth=1320
   NodeHeight=320
   NodeComment="Damage Color Shift (Lerp BodyColor → DamageColor by Damage × Blend)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=FFF4E4BF324EE196996823FE02BD8AF0
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_32"
   NodePosX=920
   NodePosY=2440
   NodeWidth=2400
   NodeHeight=520
   NodeComment="Emissive Composite (Body + Rim + Halo + Scanner + Pulse + Impact + Intersect + ActEdge) × Scanline × Flicker × Inside × (1−Holes) × Reveal"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=44DED4B223424C6FC7413DDAEE19BC79
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_33"
   NodePosX=920
   NodePosY=3020
   NodeWidth=2200
   NodeHeight=440
   NodeComment="Opacity Composite (BodyFresnel + Burst) × Base × DepthFade × CamFade × Reveal × (1−Holes)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=C8D4477C646D1A9A1A4A5E352F882FBC
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_34"
   NodePosX=920
   NodePosY=3500
   NodeWidth=1320
   NodeHeight=320
   NodeComment="WPO Bounce (optional: BounceAmount × ringSum × VertexNormalWS)"
   CommentColor=(R=0.033105,G=1.000000,B=0.132868,A=1.000000)
   NodeGuid=D9DCE437B2621D2676B54C4481E0558B
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_35"
   NodePosX=3160
   NodePosY=2520
   NodeWidth=420
   NodeHeight=220
   NodeComment="→ EMISSIVE COLOR"
   CommentColor=(R=1.000000,G=0.401978,B=0.000000,A=1.000000)
   NodeGuid=399999CB60883DE2386541EB03FBC2AD
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_36"
   NodePosX=3160
   NodePosY=3080
   NodeWidth=420
   NodeHeight=220
   NodeComment="→ OPACITY"
   CommentColor=(R=1.000000,G=0.401978,B=0.000000,A=1.000000)
   NodeGuid=9E16DB8B590B4FFFCD6A0111FA5414AB
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_37"
   NodePosX=3160
   NodePosY=260
   NodeWidth=420
   NodeHeight=220
   NodeComment="→ NORMAL"
   CommentColor=(R=1.000000,G=0.401978,B=0.000000,A=1.000000)
   NodeGuid=11F355F3C6DF0EAB742FE78225A1AD9E
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_38"
   NodePosX=3160
   NodePosY=720
   NodeWidth=420
   NodeHeight=220
   NodeComment="→ REFRACTION"
   CommentColor=(R=1.000000,G=0.401978,B=0.000000,A=1.000000)
   NodeGuid=B11FB3377CA6BADFF6F517FDF7DFD8E9
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode_Comment Name="MaterialGraphNode_Comment_39"
   NodePosX=3160
   NodePosY=3560
   NodeWidth=420
   NodeHeight=220
   NodeComment="→ WORLD POSITION OFFSET"
   CommentColor=(R=1.000000,G=0.401978,B=0.000000,A=1.000000)
   NodeGuid=FCB07A1DFE8972FD063B4BD0EC241A46
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_40"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_40"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_40"
      ParameterName="BodyColor"
      DefaultValue=(R=0.6,G=0.25,B=0.05,A=1)
      Group="00 Body"
      Desc="Soft body tint of the shield interior. Default is Death-Stranding warm amber."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-3600
      MaterialExpressionGuid=C678E5499D3AFE7A53AEEFA4969814C3
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_40'"
   NodePosX=-4400
   NodePosY=-3600
   NodeGuid=C1326FD21891E0D1A122AEC779D8E832
   CustomProperties Pin (PinId=36A46397316CF260D8B9B464F0E32B0D,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_144 C31C41BD3A13FDC378BCC46CB8DEED13,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=DB0B44FA4B6D61678ABB21A564C1D5C9,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=0B362EE49603616DBF7EE3C29B37DE73,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=7861F6756B1EDDCE09048E8AE2C3A11F,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=C25AA64D624886C3EC4A63B7FEA2B490,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_41"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_41"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_41"
      ParameterName="BodyBrightness"
      DefaultValue=1.2
      SliderMin=0
      SliderMax=8
      Group="00 Body"
      Desc="Multiplier on the body emissive. Body is what you see when looking through the shield."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-3420
      MaterialExpressionGuid=E3E3E06E48C8F7F9F849F9493AE8A99A
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_41'"
   NodePosX=-4400
   NodePosY=-3420
   NodeGuid=DDC927ABFD2C1AD9CA83FB10E8D5E0D6
   CustomProperties Pin (PinId=B4930683E446FE44E449263F6EBE8CE8,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_144 6E1769E3B4055BDFD8C61D8070AB35BB,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_42"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_42"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_42"
      ParameterName="BodyFresnelPower"
      DefaultValue=1.5
      SliderMin=0.3
      SliderMax=8
      Group="00 Body"
      Desc="Fresnel exponent for the soft body Fresnel. Lower = more body fill at face-on angles."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-3240
      MaterialExpressionGuid=D0593616A4C8AA8564CA27F5A335A7D6
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_42'"
   NodePosX=-4400
   NodePosY=-3240
   NodeGuid=12A85697B33CE6A5E6263547ABCDCEDE
   CustomProperties Pin (PinId=663E6E42190AC9D715F07093DA299549,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_140 02BF94CE6F7834F94AD72C987E7234BE,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_43"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_43"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_43"
      ParameterName="BodyFresnelBase"
      DefaultValue=0.08
      SliderMin=0
      SliderMax=1
      Group="00 Body"
      Desc="Base-reflect-fraction for the body Fresnel. Sets the minimum body brightness when looking face-on."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-3060
      MaterialExpressionGuid=5E553710AED5277D83B38C307E11199D
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_43'"
   NodePosX=-4400
   NodePosY=-3060
   NodeGuid=28731D2208AE3A2F7964A018AFBAB1EC
   CustomProperties Pin (PinId=BF7B4864536B212BE5543EF8FBF23B35,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_140 46BE1C059295FB2BD42C60DAF37EF5AD,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_44"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_44"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_44"
      ParameterName="RimColor"
      DefaultValue=(R=3,G=1.2,B=0.3,A=1)
      Group="01 Rim"
      Desc="Color of the hot knife-edge rim. Default is saturated DS orange."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-2780
      MaterialExpressionGuid=BB750D49E0FCF38FB5CF4D4C356A217B
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_44'"
   NodePosX=-4400
   NodePosY=-2780
   NodeGuid=033A331DE385043E00BB18AAAFE512A8
   CustomProperties Pin (PinId=E0A8A82CC86C150E05BB57C3359787DE,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_147 C917CE4BBE44D1DCA5005110B3615B4D,MaterialGraphNode_150 760A8ADC7D0C77842C932BC59854E3B3,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=75486CAFC376E518D57E0038613D37C7,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=8A46E9706A12E074C93D12BA28DF7734,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=DBB9AB96963CBCC8C38AC226C4916F31,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=04252DC1BD4A1CEE9C156B82CAEBCC7A,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_45"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_45"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_45"
      ParameterName="RimPower"
      DefaultValue=5
      SliderMin=1
      SliderMax=12
      Group="01 Rim"
      Desc="Fresnel exponent for the sharp rim. Higher = thinner knife edge."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-2600
      MaterialExpressionGuid=10EA3E3C7148B1C344544E39E54206EC
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_45'"
   NodePosX=-4400
   NodePosY=-2600
   NodeGuid=0F21494776F7F1319096E9433DAB443E
   CustomProperties Pin (PinId=73F00AF81D1E8F304BC756DEFF6D0985,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_145 50850C84194AC7AEDCA8310B1CE2C2F9,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_46"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_46"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_46"
      ParameterName="RimBrightness"
      DefaultValue=4
      SliderMin=0
      SliderMax=30
      Group="01 Rim"
      Desc="Multiplier on the sharp rim emissive."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-2420
      MaterialExpressionGuid=7BEF4CAD0212FF25012BC72D8163CCCE
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_46'"
   NodePosX=-4400
   NodePosY=-2420
   NodeGuid=529D2D48615CE91E6D0DF13B9EA834D7
   CustomProperties Pin (PinId=BE86B69B36D58390B64C5B658639EEFF,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_146 71FAD147798C5CB3B270A736E518B4B1,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_47"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_47"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_47"
      ParameterName="OuterHaloPower"
      DefaultValue=3
      SliderMin=1
      SliderMax=8
      Group="01 Rim"
      Desc="Wide outer fresnel exponent. Lower = wider falloff (more haloed atmospheric presence)."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-2240
      MaterialExpressionGuid=090770A8D89AB13B5DDEEE634A5A10DB
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_47'"
   NodePosX=-4400
   NodePosY=-2240
   NodeGuid=473522E67C796041862D4C89AEC07B6C
   CustomProperties Pin (PinId=72B015713ECA62D74A1CC88C24E706FD,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_148 641DD7038DF5AE9471D9A094C8B28507,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_48"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_48"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_48"
      ParameterName="OuterHaloBrightness"
      DefaultValue=1.2
      SliderMin=0
      SliderMax=8
      Group="01 Rim"
      Desc="Multiplier on the wide outer halo emissive."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-2060
      MaterialExpressionGuid=78A5AF44C21AD9FBC7A4AA231EB4D3FE
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_48'"
   NodePosX=-4400
   NodePosY=-2060
   NodeGuid=017687107349F8750D2DC397AB8338CC
   CustomProperties Pin (PinId=7F6605377BB4EF7C9AEB32E7353FCA8F,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_149 18E31C4CBDE0762E076843DAD58E5A33,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_49"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_49"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_49"
      ParameterName="InsideIntensity"
      DefaultValue=0.4
      SliderMin=0
      SliderMax=1
      Group="01 Rim"
      Desc="Backside emissive dim multiplier. 1 = same as front, 0 = invisible from inside the shield."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-1880
      MaterialExpressionGuid=DA42E45D62F821A2379455B534A1F140
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_49'"
   NodePosX=-4400
   NodePosY=-1880
   NodeGuid=A17C7B6302F85BE330E00849B9CC81E3
   CustomProperties Pin (PinId=DEF87B2C5200D875018B95D399FB6244,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_258 EEA91B7FECF05FB449500BC0059DF1BC,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_50"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_50"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_50"
      ParameterName="IntersectionFadeDistance"
      DefaultValue=8
      SliderMin=0
      SliderMax=50
      Group="02 Intersection"
      Desc="Centimeters of soft opacity fade where the shield meets opaque geometry. Also drives the contact-glow band width."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-1580
      MaterialExpressionGuid=10173F5EE975E9F2CBEBC170285F0546
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_50'"
   NodePosX=-4400
   NodePosY=-1580
   NodeGuid=0427F9A566ABB9EBD0E338A98EAFDBAC
   CustomProperties Pin (PinId=38CBFA33ACBC7A594D15EB84D79E5A2A,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_151 3811697AAC6C8611CF6AADD69AF669B6,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_51"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_51"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_51"
      ParameterName="IntersectionGlowBrightness"
      DefaultValue=3
      SliderMin=0
      SliderMax=50
      Group="02 Intersection"
      Desc="Brightness of the hot rim where the shield touches geometry. 0 = off (in-space). Crank for grounded shields."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-1400
      MaterialExpressionGuid=79EC8943CF67BC5B3808E5FFABB2B799
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_51'"
   NodePosX=-4400
   NodePosY=-1400
   NodeGuid=633B94F207337524FA4BCFF9C3D7216E
   CustomProperties Pin (PinId=1E40C16AA150F1860050FCE09BB7C7D2,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_153 3AE5B91BA2BFF46948F39B45008E2BD6,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_52"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_52"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_52"
      ParameterName="IntersectionGlowColor"
      DefaultValue=(R=3.5,G=1.4,B=0.4,A=1)
      Group="02 Intersection"
      Desc="Color of the contact-glow band."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-1220
      MaterialExpressionGuid=188F1126377892E24116D76EF4190B45
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_52'"
   NodePosX=-4400
   NodePosY=-1220
   NodeGuid=C4C0ED4FD3CD3D97B1F617E21398B5BB
   CustomProperties Pin (PinId=9DA1723F2874E64C3600F3BA040D913F,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_154 30ED7210ECE8D2C6CE2AFDCB1A7B1FBA,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=8F74AFAEE7342FCC8F7058F55E6171A6,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=8F4274F6023B13E8A61E745BE4BB3FDF,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=FF79837CE7E1E11F1E89E1D2BAAF48C8,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=35DB07F24224BB0C43D409EC439B3FD2,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_53"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_53"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_53"
      ParameterName="ScannerRingFrequency"
      DefaultValue=10
      SliderMin=0.5
      SliderMax=40
      Group="03 Scanner Rings"
      Desc="Number of concentric rings visible across the shield's local size. Higher = more, tighter rings."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-920
      MaterialExpressionGuid=BCCF06F09691D7540E50F461B9C771C3
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_53'"
   NodePosX=-4400
   NodePosY=-920
   NodeGuid=EEA61659339561D25EF6BA5BAB01BBFB
   CustomProperties Pin (PinId=9DBB830D40EA66C601BF17FCDB9646B8,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_156 2C0A16174187DB233E13A9C4623A0420,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_54"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_54"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_54"
      ParameterName="ScannerRingSpeed"
      DefaultValue=0.35
      SliderMin=-3
      SliderMax=3
      Group="03 Scanner Rings"
      Desc="Drift speed. Positive = rings drift outward from object center, negative = inward. 0 = static."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-740
      MaterialExpressionGuid=B74E59A2687F13427D289E3279E91FDC
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_54'"
   NodePosX=-4400
   NodePosY=-740
   NodeGuid=10FEB35151C91F1FBC6862126AC731F9
   CustomProperties Pin (PinId=7889A1246072A95DDD7975DCFA8702DE,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_157 B19A022B290ED3EACAB29BFBD5C0D674,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_55"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_55"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_55"
      ParameterName="ScannerRingSharpness"
      DefaultValue=4
      SliderMin=1
      SliderMax=20
      Group="03 Scanner Rings"
      Desc="Pow on the ring profile. Higher = thinner, more contrast-y rings."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-560
      MaterialExpressionGuid=973E60563A73A0437FC57CD7CC90ABE9
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_55'"
   NodePosX=-4400
   NodePosY=-560
   NodeGuid=19AF1473775A980A4B94DBF3D4C688AB
   CustomProperties Pin (PinId=EC300387FEB351F86276CDC6F90A6F7D,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_56"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_56"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_56"
      ParameterName="ScannerRingBrightness"
      DefaultValue=3
      SliderMin=0
      SliderMax=20
      Group="03 Scanner Rings"
      Desc="Emissive multiplier on the rings. 0 = disable scanner ring layer."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-380
      MaterialExpressionGuid=75D1167DAA8F831D48592101F820FE51
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_56'"
   NodePosX=-4400
   NodePosY=-380
   NodeGuid=456C626513FDDA31ECC2E14CA3E552F6
   CustomProperties Pin (PinId=8C54AA8BC43B42EA6C8297075B0C1432,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_167 B89C53E934B834355553F46C8596B8FB,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_57"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_57"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_57"
      ParameterName="ScannerRingColor"
      DefaultValue=(R=2.4,G=1.5,B=0.6,A=1)
      Group="03 Scanner Rings"
      Desc="Ring color. Default is warm orange-amber matching the DS chiral palette."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-200
      MaterialExpressionGuid=C25FA73314D4D7708D1BB8AA5C1CEDB9
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_57'"
   NodePosX=-4400
   NodePosY=-200
   NodeGuid=9D65C665D08931E05724832329E2D333
   CustomProperties Pin (PinId=E052C1B4F0154B50DF88FFB05A7116AD,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_168 2A218F04B29BDF46CE76CF68ABDD4388,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=718F9E0875B524B5C073F3910D5EDC28,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=58ABBA5C4C99C9A81FD97A7E1F828D9F,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=E6708CF6972CD95318719837B63F2AF7,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=0354A29546A054A6E83A5EC35C37906D,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_58"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_58"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_58"
      ParameterName="PatternFresnelMaskPower"
      DefaultValue=1.8
      SliderMin=0.3
      SliderMax=6
      Group="03 Scanner Rings"
      Desc="Fresnel exponent used to bias scanner rings toward the silhouette. Higher = rings live mostly at glancing angles."
      MaterialExpressionEditorX=-4400
      MaterialExpressionEditorY=-20
      MaterialExpressionGuid=3A0D12278AB73CFE462ECD867261F1BE
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_58'"
   NodePosX=-4400
   NodePosY=-20
   NodeGuid=436C8DBA2815C66ED9FCF75D4F0B574E
   CustomProperties Pin (PinId=6756805CF0E0C48FBB2D19674FB5DF55,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_165 0ECBFF9602D3EEF888247698205FD998,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_59"
   Begin Object Class=/Script/Engine.MaterialExpressionTextureObjectParameter Name="MaterialExpressionTextureObjectParameter_59"
   End Object
   Begin Object Name="MaterialExpressionTextureObjectParameter_59"
      ParameterName="FlowNoiseTexture"
      Group="04 Energy Flow"
      Texture=Texture2D'/Engine/EngineMaterials/Good64x64TilingNoiseHighFreq.Good64x64TilingNoiseHighFreq'
      Desc="Tiling greyscale noise texture used for energy-flow modulation, distortion normals, activation-edge break, and damage instability. Default is engine-content tiling noise — swap for any tiling noise."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-3600
      MaterialExpressionGuid=344528B2CA4CD0C46E6214B116B750F4
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionTextureObjectParameter'MaterialExpressionTextureObjectParameter_59'"
   NodePosX=-3800
   NodePosY=-3600
   NodeGuid=A4EDB4BA9F4354D26A6322A902A8BCD8
   CustomProperties Pin (PinId=09FD42545BE2A2F0C48E4431004DFA90,PinName="UVs",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=0AD40B0D0CED6946112B4100D506A3E2,PinName="ApplyViewMipBias",PinType.PinCategory="optional",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=19332B335B02A629F124EC4AA1AA086B,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_Custom_135 5F8013C1B42F632CD0C98F03A2106213,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_60"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_60"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_60"
      ParameterName="FlowScale"
      DefaultValue=2.5
      SliderMin=0.5
      SliderMax=20
      Group="04 Energy Flow"
      Desc="Tiling rate of the energy-flow noise across the shield surface."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-3420
      MaterialExpressionGuid=9FC2A26C00115528EAE01493FD93BFC7
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_60'"
   NodePosX=-3800
   NodePosY=-3420
   NodeGuid=AB54F4A83F4395FEF4334B8370FF9B66
   CustomProperties Pin (PinId=71FD230ECCED6F80F0124B19A2F50360,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_175 7A184CA4374EC215DD9B1374C1799E84,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_61"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_61"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_61"
      ParameterName="FlowSpeed"
      DefaultValue=0.05
      SliderMin=0
      SliderMax=1
      Group="04 Energy Flow"
      Desc="Pan rate of the flow noise. Reads as plasma drifting across the shield."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-3240
      MaterialExpressionGuid=5C19F9550F7D6C18DE1D7270FEC37095
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_61'"
   NodePosX=-3800
   NodePosY=-3240
   NodeGuid=47942125083A2A3864E93008410DFBDB
   CustomProperties Pin (PinId=087F94FC325592B2DE460CB414C90DBC,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_173 6240BF4B0BFE7FA296771E8501DD40DB,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_62"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_62"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_62"
      ParameterName="FlowStrength"
      DefaultValue=0.4
      SliderMin=0
      SliderMax=2
      Group="04 Energy Flow"
      Desc="How much the flow noise modulates the body+scanner brightness. 0 = uniform, 1 = full molten variation."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-3060
      MaterialExpressionGuid=4C8A4B729188DA4E69B688934AA4AC6A
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_62'"
   NodePosX=-3800
   NodePosY=-3060
   NodeGuid=F7C169730031E441370F1AD456C0737C
   CustomProperties Pin (PinId=7FD07301E8637CC19826C7C8B8D0A7DA,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_180 843E64C808CE232D37B9808CE841B66D,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_63"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_63"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_63"
      ParameterName="PulseRingFrequency"
      DefaultValue=4
      SliderMin=0.5
      SliderMax=20
      Group="04 Energy Flow"
      Desc="Number of slow body-pulse rings (object-center distance-based sine pulse). Bigger feature than scanner rings; reads as a heartbeat."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-2880
      MaterialExpressionGuid=15A38117AFB97A9138A9C3DDFD28A7D9
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_63'"
   NodePosX=-3800
   NodePosY=-2880
   NodeGuid=ECEEE2766A08F3D55A19BE396385E697
   CustomProperties Pin (PinId=DAF2EA00898B8FFD963ED7501885D588,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_183 107189029B91DD8D1BB7DC58EA4067A5,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_64"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_64"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_64"
      ParameterName="PulseRingSpeed"
      DefaultValue=0.5
      SliderMin=0
      SliderMax=5
      Group="04 Energy Flow"
      Desc="Rate of the body pulse rings (Hz). Independent from the scanner ring drift."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-2700
      MaterialExpressionGuid=75E29AB593FB8C7485B420E5C6134243
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_64'"
   NodePosX=-3800
   NodePosY=-2700
   NodeGuid=B800EE426340BA79683563920F1B62FE
   CustomProperties Pin (PinId=F6ACEC237D1D3517C755EC701E41B5D8,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_184 852CB0D8DBB0928134D420B28C1127A7,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_65"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_65"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_65"
      ParameterName="PulseRingStrength"
      DefaultValue=0.6
      SliderMin=0
      SliderMax=3
      Group="04 Energy Flow"
      Desc="Emissive contribution of the body pulse rings."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-2520
      MaterialExpressionGuid=D3067DCCEF6DE891689145AFA8D50222
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_65'"
   NodePosX=-3800
   NodePosY=-2520
   NodeGuid=DDC5971DD16A2BABF375684CFCC836BF
   CustomProperties Pin (PinId=3BD8787E680724F717230492545221E2,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_190 481AA681E3FCA51D9EA690FD26669EEA,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_66"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_66"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_66"
      ParameterName="PulseRingColor"
      DefaultValue=(R=1.6,G=0.9,B=0.3,A=1)
      Group="04 Energy Flow"
      Desc="Color of the body pulse rings."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-2340
      MaterialExpressionGuid=C01C1419B2A3BFC2D233F119C0DC7E93
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_66'"
   NodePosX=-3800
   NodePosY=-2340
   NodeGuid=4703B51A85A6236499DE54FB4C1E25E3
   CustomProperties Pin (PinId=58638A0D7F3EB1D94E9AEF67BBFF7E87,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_191 E14F8998DDC09E8637B6313A247CF5E6,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=DB6E26F6379DDF1FB5F793CE26553219,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=D5A16C9414DE94993CD27D8094DF6005,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=B3724A6D27356F67E3DA7D1C48C9931C,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=E34635DD640AFD846727B617B3A6AE03,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_67"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_67"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_67"
      ParameterName="ScanlineFrequency"
      DefaultValue=16
      SliderMin=0
      SliderMax=80
      Group="04 Energy Flow"
      Desc="World-Z scanline frequency. Reads as horizontal energy bands sliding through the shield."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-2160
      MaterialExpressionGuid=1B9A9DCE28E43CAEE76D30E80FB3D952
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_67'"
   NodePosX=-3800
   NodePosY=-2160
   NodeGuid=0087A8A2EE0E57B2545689C083BB31FC
   CustomProperties Pin (PinId=20CAB5E5261EB3E47250E53A50770F5A,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_192 A3C78993C65717CA238948ED88FA3E10,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_68"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_68"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_68"
      ParameterName="ScanlineSpeed"
      DefaultValue=0.4
      SliderMin=-3
      SliderMax=3
      Group="04 Energy Flow"
      Desc="Scanline drift speed. Positive = upward, negative = downward, 0 = static."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-1980
      MaterialExpressionGuid=1A9AA1D8AA3F4F1F359942EFFC57503D
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_68'"
   NodePosX=-3800
   NodePosY=-1980
   NodeGuid=2EE772CE717BE94BBC016370EC0A359F
   CustomProperties Pin (PinId=420E457F612EAC31CA4490EB47C56208,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_193 BE0DF75A06BBB7404EF481B6C9D3FBB3,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_69"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_69"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_69"
      ParameterName="ScanlineStrength"
      DefaultValue=0.2
      SliderMin=0
      SliderMax=1
      Group="04 Energy Flow"
      Desc="How strongly scanlines modulate the body brightness. 0 = disabled."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-1800
      MaterialExpressionGuid=8484F60B5FECBA6131A3B67A8979F6A3
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_69'"
   NodePosX=-3800
   NodePosY=-1800
   NodeGuid=6731514F87B8FF24F8E6B3DC870A7C71
   CustomProperties Pin (PinId=0E0C1AD16D117EF428453CE05611F5CD,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_199 10E3D15FC631320589385B6D52462D0A,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_70"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_70"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_70"
      ParameterName="DistortNoiseScale"
      DefaultValue=3
      SliderMin=0.5
      SliderMax=30
      Group="05 Distortion"
      Desc="Tiling of the distortion noise (drives the rippling normal perturbation)."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-1500
      MaterialExpressionGuid=E316E45C59AF797EB5D05D8D8FAA29C0
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_70'"
   NodePosX=-3800
   NodePosY=-1500
   NodeGuid=022596C697D4E82474E2B6B2339189D2
   CustomProperties Pin (PinId=FC5ADD096C5F2ED92A1CFE0B1364AC08,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_209 552AA8E116F2A7B94FD847302D829597,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_71"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_71"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_71"
      ParameterName="DistortNoiseSpeed"
      DefaultValue=0.1
      SliderMin=0
      SliderMax=2
      Group="05 Distortion"
      Desc="Pan speed of the distortion noise. Higher = faster surface shimmer."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-1320
      MaterialExpressionGuid=235CB3EAF35797E467D03F9FF559F5E8
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_71'"
   NodePosX=-3800
   NodePosY=-1320
   NodeGuid=025673717090E12F0A4008E8E3FBB424
   CustomProperties Pin (PinId=979380E8F67C60C35B94FB2128ABC2A8,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_207 6658D776C3E34CAE4784A0D8AB86CABD,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_72"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_72"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_72"
      ParameterName="DistortStrength"
      DefaultValue=0.04
      SliderMin=0
      SliderMax=0.5
      Group="05 Distortion"
      Desc="Base refraction strength at normal incidence. Keep small — under 0.1 — to avoid screen-tearing."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-1140
      MaterialExpressionGuid=7CC089BE36B94BB578EFDAB2D8E75BED
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_72'"
   NodePosX=-3800
   NodePosY=-1140
   NodeGuid=BD90E9FDFB59CC7302546C1784D68E5E
   CustomProperties Pin (PinId=18C40298C35DEB2CB22933C4EE401309,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_216 4639C39598C2B100C00CE1D9B389E9F5,MaterialGraphNode_217 151EA02488F61C9AA45B371FF80FF67A,MaterialGraphNode_226 3CF44FCFD79725D2DA783C9D0D2106FA,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_73"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_73"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_73"
      ParameterName="DistortEdgeBoost"
      DefaultValue=3
      SliderMin=0
      SliderMax=10
      Group="05 Distortion"
      Desc="Multiplier on the edge-fresnel-concentrated distortion. Higher = stronger edge bend, less center bend."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-960
      MaterialExpressionGuid=6778FE1EED51AE90389AA1AF4EA01EDB
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_73'"
   NodePosX=-3800
   NodePosY=-960
   NodeGuid=7607E4667E3FAA2510BC9CBD797E7C80
   CustomProperties Pin (PinId=954D64F00559D8D5D59E0CC5061337B4,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_223 4D9AD3E732FA70A894C8AEB591189469,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_74"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_74"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_74"
      ParameterName="ImpactDistortBoost"
      DefaultValue=3.5
      SliderMin=0
      SliderMax=20
      Group="05 Distortion"
      Desc="Multiplier on the localized distortion spike at impact ring crests."
      MaterialExpressionEditorX=-3800
      MaterialExpressionEditorY=-780
      MaterialExpressionGuid=5728A375192BD892F0591457B35412F7
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_74'"
   NodePosX=-3800
   NodePosY=-780
   NodeGuid=87C06A2734001007E806FA4D3CB3EF5F
   CustomProperties Pin (PinId=2E5BFDE0315623A0BBAA6AC0D7F71137,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_224 B25D9C79588B81990526E05DAA3DEFA5,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_75"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_75"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_75"
      ParameterName="ImpactPos1"
      DefaultValue=(R=0,G=0,B=0,A=0)
      Group="06 Impacts"
      Desc="World-space origin of impact ripple slot #1."
      MaterialExpressionEditorX=-3200
      MaterialExpressionEditorY=-3600
      MaterialExpressionGuid=AD3D00C868A7D0D5609EDAFAB29232F1
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_75'"
   NodePosX=-3200
   NodePosY=-3600
   NodeGuid=CA3A0972729917496B8F3165C1B97BEE
   CustomProperties Pin (PinId=0A818EEF83627DF8EDF65F92457FA614,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_Custom_135 78D94F16D29E6973FE0DB01D99877B49,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=662746C5F20E712EF8F82264497E1309,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=5912EC2DE60F676D9885B4817F793336,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=0E4BAC9E11BB209945B95A56F98DCA07,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=0B4D4745C0F90C2CB6DC574B74FFE749,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_76"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_76"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_76"
      ParameterName="ImpactTime1"
      DefaultValue=-100
      SliderMin=-100
      SliderMax=100
      Group="06 Impacts"
      Desc="Game time when impact #1 fired. Drive from BP via SetScalarParameterValue with current Time on hit. Default -100 = fully decayed."
      MaterialExpressionEditorX=-3200
      MaterialExpressionEditorY=-3420
      MaterialExpressionGuid=7C93BFD4FB98EEFF63752A7AA55EC36E
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_76'"
   NodePosX=-3200
   NodePosY=-3420
   NodeGuid=9E844F5587C3560BE0622189A6064C9A
   CustomProperties Pin (PinId=04C6F6E78A4635BBC8DA5036D6EB3A00,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_Custom_135 E07D6A7A8ECF9DBD97039C7190F8FA98,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_77"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_77"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_77"
      ParameterName="ImpactPos2"
      DefaultValue=(R=0,G=0,B=0,A=0)
      Group="06 Impacts"
      Desc="World-space origin of impact ripple slot #2."
      MaterialExpressionEditorX=-3200
      MaterialExpressionEditorY=-3240
      MaterialExpressionGuid=6A32C4F1CD2D8BB74A024FDED81570D0
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_77'"
   NodePosX=-3200
   NodePosY=-3240
   NodeGuid=A147FF52950EAA680C4E3E0216A634DD
   CustomProperties Pin (PinId=0A979E6768B5E019E64817459AF7C6E6,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_Custom_135 EB4ED1F444B34EA7C27734B528F6FAEB,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=ADD23F1EF6C0FF95918DEF0A3F49458F,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=36E2AA71CBB9AFCA3E20E299765BC71F,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=8AA66D668F5A9CC8CD56C3CD38B677DA,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=2B3C47367DBADCB25526FD21460071E5,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_78"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_78"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_78"
      ParameterName="ImpactTime2"
      DefaultValue=-100
      SliderMin=-100
      SliderMax=100
      Group="06 Impacts"
      Desc="Game time when impact #2 fired."
      MaterialExpressionEditorX=-3200
      MaterialExpressionEditorY=-3060
      MaterialExpressionGuid=780D3296E0B23AE35AC9CF00D65F3FA4
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_78'"
   NodePosX=-3200
   NodePosY=-3060
   NodeGuid=DAD02C8B8D3E3F33C0F4F54BEF084FB7
   CustomProperties Pin (PinId=0CA0A815BF266E01D42313874D4B771E,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_Custom_135 5632BBB5D473E044483F91BF5400FB91,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_79"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_79"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_79"
      ParameterName="ImpactPos3"
      DefaultValue=(R=0,G=0,B=0,A=0)
      Group="06 Impacts"
      Desc="World-space origin of impact ripple slot #3."
      MaterialExpressionEditorX=-3200
      MaterialExpressionEditorY=-2880
      MaterialExpressionGuid=F7A7F3F85C95EA78B24528BF2BF85994
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_79'"
   NodePosX=-3200
   NodePosY=-2880
   NodeGuid=49D478E565B33C30FD38AF6BA8AC63F8
   CustomProperties Pin (PinId=4C92F6955A3912EB24C8A5288C152A35,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_Custom_135 1F1FDFB5D00876E3219E941BE2260728,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=4BDBE26AAE9885C191C29C4E608569F6,PinName="R",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=E93A387DD4A3F6738E0A1ED5B8F0AC16,PinName="G",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=1B752210EC6C0BAF63F86C7962471D8E,PinName="B",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
   CustomProperties Pin (PinId=4C4E6937897D54AD3378F0BF0F0CAFA0,PinName="A",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_80"
   Begin Object Class=/Script/Engine.MaterialExpressionScalarParameter Name="MaterialExpressionScalarParameter_80"
   End Object
   Begin Object Name="MaterialExpressionScalarParameter_80"
      ParameterName="ImpactTime3"
      DefaultValue=-100
      SliderMin=-100
      SliderMax=100
      Group="06 Impacts"
      Desc="Game time when impact #3 fired."
      MaterialExpressionEditorX=-3200
      MaterialExpressionEditorY=-2700
      MaterialExpressionGuid=68A0043B621EBE554DE9AC8DE1372368
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionScalarParameter'MaterialExpressionScalarParameter_80'"
   NodePosX=-3200
   NodePosY=-2700
   NodeGuid=27C1D35C440C81AD796DD86FEB807D0F
   CustomProperties Pin (PinId=B64F9CD39E0B2C34EE34E1D9C907CEBB,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_Custom_135 2218043E32A1A921A1AF1E18F1EE91AE,),PersistentGuid=00000000000000000000000000000000,bHidden=False,bNotConnectable=False,bDefaultValueIsReadOnly=False,bDefaultValueIsIgnored=False,bAdvancedView=False,bOrphanedPin=False)
End Object

Begin Object Class=/Script/UnrealEd.MaterialGraphNode Name="MaterialGraphNode_81"
   Begin Object Class=/Script/Engine.MaterialExpressionVectorParameter Name="MaterialExpressionVectorParameter_81"
   End Object
   Begin Object Name="MaterialExpressionVectorParameter_81"
      ParameterName="ImpactPos4"
      DefaultValue=(R=0,G=0,B=0,A=0)
      Group="06 Impacts"
      Desc="World-space origin of impact ripple slot #4."
      MaterialExpressionEditorX=-3200
      MaterialExpressionEditorY=-2520
      MaterialExpressionGuid=4FC165A3DD316C2A25896AF85FC0197B
      Material="/Script/UnrealEd.PreviewMaterial'/Engine/Transient.Pasted_material'"
   End Object
   MaterialExpression="/Script/Engine.MaterialExpressionVectorParameter'MaterialExpressionVectorParameter_81'"
   NodePosX=-3200
   NodePosY=-2520
   NodeGuid=B8B13D752B09B64B78D4E27DBA517804
   CustomProperties Pin (PinId=EEE1E4AF38D032515BEC876FBB915796,PinName="Output",Direction="EGPD_Output",PinType.PinCategory="",PinType.PinSubCategory="",PinType.PinSubCategoryObject=None,PinType.PinSubCategoryMemberReference=(),PinType.PinValueType=(),PinType.ContainerType=None,PinType.bIsReference=False,PinType.bIsConst=False,PinType.bIsWeakPointer=False,PinType.bIsUObjectWrapper=False,PinType.bSerializeAsSinglePrecisionFloat=False,LinkedTo=(MaterialGraphNode_Custom_135 AFD0A54D5F12472B45B9CCF97EBAB2EB,),PersistentGuid=0000000000000000000000
…

Source truncated for rendering. Use Copy to grab the full 608 KB.

Nodes: ScalarParameter (x59), Multiply (x57), Comment (x40), Add (x19), Constant (x13), VectorParameter (x12), ComponentMask (x11), Subtract (x8), Saturate (x6), Fresnel (x5), Sine (x4), Constant2Vector (x3), Divide (x3), OneMinus (x3), Panner (x3), TextureSample (x3), AppendVector (x2), Distance (x2), LinearInterpolate (x2), CameraPositionWS, Custom, DepthFade, Length, LocalPosition, Material, Normalize, ObjectBounds, ObjectPositionWS, ObjectRadius, Power, TextureObjectParameter, Time, Transform, TwoSidedSign, VertexNormalWS, WorldPosition

more from @hazesee all

Water Puddle

@hazeUE 5.7

Caustics (Light Function)

@hazeUE 5.5+

Holographic Signs

@hazeUE 5.6+

More like this

browse all

Laser Grid / Security Barrier

@eeveeUE 5.6+

Holographic Signs

@hazeUE 5.6+

Sci-fi Signal Glitch PP

@hazeUE 5.6+

Force Field

@hazefounder
Nanite-friendly
UE 5.6UE 5.7
8
license

CC0 1.0: Public Domain

Public domain: use it however you like, no credit required.

dependencies

Zero dependencies

Pastes and works in any UE 5.3+ project. No textures, no material functions, no MPCs.

tags
#force-field#halo#sphere#refraction#pulse#sci-fi#shield
ue compatibility
UE 5.3UE 5.4UE 5.5UE 5.6UE 5.7

Details

Last update
3 days ago
Published
14 days ago
Nodes
272
